POLYCAB 1.1KV 3.5C*185SQMM ALU. ARM. LT CABLE

POLYCAB 1.1KV 3.5C*185SQMM ALU. ARM. LT CABLE Specification

No Of Core
3.5 Core

Product Type
LT cable

Function
Power Supply

Usage
Power Supply

Voltage Surge
1.1 KV

Frequency (MHz)
50/60 Hertz (HZ)

Rated Voltage
1.1 KV Volt (V)

Insulation Material
XLPE/PVC

Cable Type
Low Voltage Transmission Cable

Conductor Material
Aluminum

Length
100 Meter (m)

Phase
Single / Three

Size
185 sqmm

Features
High Conductivity

Material
Aluminum

Color
Black

Frequency
50/60Hz Hertz (HZ)

Diameter
185 sqmm Millimeter (mm)

Application
Power Transmission

About POLYCAB 1.1KV 3.5C*185SQMM ALU. ARM. LT CABLE

POLYCAB 1.1KV 3.5C x 185 SQMM ALUMINIUM ARMOURED LT CABLE

The Polycab 1.1kV 3.5 Core x 185 sqmm Aluminium Armoured LT Cable is a heavy-duty low-tension power cable, designed to deliver safe and efficient electricity distribution across industrial, commercial, and utility applications. Built with high-quality aluminium conductors, XLPE/PVC insulation, and strong armouring, it ensures long service life and superior performance under demanding conditions.

Rated Voltage: 1.1kV (Low Tension)
Conductor Material: Aluminium
Conductor Size: 185 sqmm
Number of Cores: 3.5 Core (3 full cores + reduced neutral)
Insulation: XLPE/PVC insulation providing excellent dielectric strength and thermal stability
Armouring: Galvanized Steel Strip/Wire Armour for enhanced mechanical protection
Outer Sheath: Heavy-duty PVC sheath, resistant to heat, moisture, oils, chemicals, and UV radiation
Standards: Manufactured as per IS 7098 (Part-1) / IS 1554 (Part-1)

Applications:

Ideal for LT power distribution networks in industrial plants, substations, utilities, and commercial complexes.
Suitable for underground cabling, outdoor installations, ducts, and cable trays.
Commonly used in large-scale infrastructure and heavy electrical load environments.

Key Features:

High conductivity aluminium conductor ensures efficient and cost-effective power transmission.
3.5 Core design offers optimal neutral sizing for balanced load distribution.
Robust armouring provides superior protection against mechanical damage and rodent attacks.
Flame-retardant, UV resistant, weatherproof, and durable for long operational life.

Designed for Efficient Power Transmission

This POLYCAB cable's 3.5-core construction and robust armoring make it ideal for distributing electrical power safely and efficiently. Its 185 sqmm diameter and aluminium conductor ensure low power loss and excellent current-carrying capability.

Built to Withstand Harsh Conditions

Equipped with premium XLPE or PVC insulation and a durable armoured sheath, this cable resists mechanical damage, moisture, and thermal stress. It performs reliably in indoor and outdoor installations.

Versatile Application Across Industries

Suitable for use in industrial plants, utilities, and commercial settings, the cable supports both single and three-phase systems. Its flexible design meets the needs of new installations and upgrading existing power infrastructures.

FAQ's of POLYCAB 1.1KV 3.5C*185SQMM ALU. ARM. LT CABLE:

**Q: How is the POLYCAB 1.1KV 3.5C*185SQMM cable typically installed?**

A: This cable is usually installed through trenches, ducts, or laid directly underground, thanks to its armoured construction. It is designed for both indoor and outdoor settings, providing flexibility for different project requirements.

Q: What are the primary benefits of using an armoured low voltage cable for power transmission?

A: Armoured cables like this POLYCAB model offer enhanced mechanical protection, reducing the risk of damage from external forces. Their robust build ensures long service life and stable power supply under various environmental conditions.

Q: When should I use a 3.5-core, 185 sqmm cable for my project?

A: A 3.5-core, 185 sqmm cable is perfect for high-capacity power transmission in both single and three-phase systems, especially where significant current is required, such as in industrial or commercial power distribution networks.

Q: Where is this POLYCAB cable most commonly applied?

A: This cable is commonly used in power plants, manufacturing units, commercial complexes, and public utility projects across India. Its versatility makes it suitable for any installation that demands reliable, high-capacity power delivery.

Q: What is the process for sourcing the POLYCAB 1.1KV cable in India?

A: The cable can be purchased through authorized distributors, suppliers, manufacturers, and traders throughout India. Verification of supplier authenticity is recommended for guaranteed quality and compliance.

Q: How does the XLPE/PVC insulation enhance cable performance?

A: XLPE and PVC insulation provide excellent electrical resistance, thermal stability, and protection against moisture, which helps maintain consistent cable performance and minimizes the risk of electrical faults.

Q: What are the main usage scenarios for this aluminum armoured power cable?

A: This cable is used for delivering reliable power in low-voltage transmission lines, especially in environments where mechanical protection and high conductivity are essential for safety and efficiency.
