COMPAQ 33KV 400SQMM OUTDOOR TERMINATION KIT

COMPAQ 33KV 400SQMM OUTDOOR TERMINATION KIT Trade Information

Minimum Order Quantity
1 Number

Delivery Time
2 Days

About COMPAQ 33KV 400SQMM OUTDOOR TERMINATION KIT

What is a 33 kV 3C 400 sq mm Outdoor Termination Kit and Where Its Used

A termination kit is used to terminate the end of a medium-voltage cable (here 33 kV) and connect it safely and reliably to switchgear, transformer bushings, overhead/pole-mounted terminations or other 33 kV equipment, ensuring insulation, earthing/shield continuity, mechanical protection and environmental sealing. Axis India+2indogermanpower.com+2
The 3-core 400 sq mm specification indicates a 3-phase cable with conductor cross-section of 400 mm a standard size in many HT (33 kV) underground or distribution networks. Power and Cables+2techbaniya.com+2
Outdoor means the termination kit is designed to withstand external environmental conditions moisture, rain, UV, dust, temperature variations etc. typically used for outdoor substation terminations, pole-mounted terminations, cable-box outdoors or open/partially exposed termination points. Axis India+2yamunapower.com+2

Such kits are essential when laying 33 kV XLPE (or similar) underground / distribution cables that eventually terminate outside e.g. at transformer bushings, pole-mounted switchgear or outdoor cable enclosures.

Typical Components Inside the Outdoor Termination Kit

Based on standard heat-shrink / outdoor-rated 33 kV termination kits for 3-core 240400/300400 sq mm cables a 3C 400 sq mm kit generally includes: indogermanpower.com+4Power and Cables+4ETS Cable Components+4

Component / Material	Purpose / Function
Heat-shrinkable stress-control tubing + stress-control mastic/cone (one per core)	To manage the electric stress at the cut end of insulation, avoiding partial discharge or insulation failure essential at 33 kV. indogermanpower.com+2ETS Cable Components+2
Heat-shrinkable insulating / semi-conducting tubing per core (core insulation + screen-shielding if cable has metallic screen)	Provides re-insulation and restores screen/shield continuity if cable is screened / armoured. Power and Cables+1
Outer protective jacket / re-jacketing sleeve (heat-shrink or cold-shrink) + weather-resistant outer sheath	For mechanical protection, UV, moisture, dust and environmental sealing vital for outdoor exposures. Axis India+2indogermanpower.com+2
Earthing / screening materials e.g. copper braid/tape, mesh, solderless earth lug / clamp (for screened or armoured cables)**	To ensure metallic screen/armour continuity and safe earthing for cable and shield. Power and Cables+2indogermanpower.com+2
Trifurcation / breakout boot (for 3-core) or stress-relief boot / skirt (as required in outdoor terminations)	Used to manage the transition from combined 3-core cable to individual cores provides mechanical strength and sealing at the crotch area. indogermanpower.com+2techbaniya.com+2
Sealing compounds, mastic, tapes, anti-tracking tubing, anti-tracking sheds or rain-sheds / creepage extenders (as required)	For moisture-proofing, anti-tracking, erosion resistance, and long-term reliability under outdoor conditions
