COMPAQ 33KV 3C*300SQMM INDOOR TERMINATION KIT

About COMPAQ 33KV 3C*300SQMM INDOOR TERMINATION KIT

COMPAQ 33kV 3C 300 sqmm Indoor Termination Kit

The COMPAQ 33kV 3 Core 300 sqmm Indoor Termination Kit is a premium-quality, high-voltage cable termination solution engineered to deliver reliable performance and superior safety in indoor installations. It is designed specifically for 33kV class XLPE insulated, armoured aluminium or copper cables, ensuring long-term electrical integrity and mechanical protection at high operating voltages.

Product Overview

COMPAQs indoor termination kits are developed using advanced heat shrink technology and high-grade insulating materials that ensure excellent electrical performance, mechanical endurance, and resistance to environmental stress. The termination kit provides a dependable interface between high-voltage power cables and indoor electrical equipment such as switchgear, transformers, and control panels.

The design incorporates advanced stress control and sealing components to eliminate partial discharges, prevent moisture ingress, and maintain the insulation properties of the cable throughout its operational life.

Technical Features and Advantages

1. Rated Voltage: 33kV (UE/E)

2. Cable Size Compatibility: 3 Core 300 sqmm

3. Cable Type: XLPE insulated, armoured, aluminium or copper conductor

4. Technology: Heat Shrink Type (Indoor Application)

5. Operating Temperature Range: -40C to +105C

Key Advantages:

• Excellent Electrical Insulation: Provides consistent dielectric performance even under high electrical stress, ensuring reliable power transmission.

• Advanced Stress Control: Incorporates stress grading materials to evenly distribute electrical stress, reducing the risk of insulation breakdown.

• Moisture and Dust Protection: The heat shrink tubing ensures an airtight and watertight seal for enhanced longevity.

• Thermal and Mechanical Strength: High resistance to thermal aging, vibration, and mechanical impact.

• Easy Installation: Pre-engineered design for fast, simple, and error-free installation, minimizing downtime.

• Maintenance-Free Operation: Once installed, it requires virtually no maintenance, ensuring long service life.

Applications

The COMPAQ 33kV Indoor Termination Kit is suitable for a wide range of power distribution and industrial applications, including:

• Indoor substations and switchgear rooms

• Industrial plants and manufacturing facilities

• Commercial complexes with high-voltage electrical systems

• Renewable energy projects such as solar and wind power plants

• Distribution transformers and control panels

Construction and Design

Each termination kit includes high-quality components such as:

• Heat shrinkable insulation tubing

• Stress control tubing

• Lug sealing mastic and breakout boots

• Earth connection components

• Cleaning and preparation materials

• Detailed installation instructions

The heat shrink components are made of cross-linked polyolefin materials with excellent tracking resistance and electrical strength. The design ensures reliable termination performance even under fluctuating load conditions and varying indoor environmental factors.

Standards and Quality Assurance

COMPAQ termination kits are tested and manufactured as per international standards:

• IS 13573 (Part 1)

• IEC 60840 / IEC 60502-4

• CENELEC HD 629.1 S2

Each kit undergoes rigorous factory testing to ensure high performance, reliability, and consistency.

Conclusion

The COMPAQ 33kV 3C 300 sqmm Indoor Termination Kit offers a durable, efficient, and safe solution for high-voltage cable terminations in indoor environments. Backed by COMPAQs commitment to innovation and quality, it ensures optimal electrical performance, ease of installation, and long-term reliability, making it the preferred choice for power utilities, contractors, and industrial users worldwide.
